Product Overview
The Miflex Carbon HD High Pressure Gauge Hose connects your regulator’s high-pressure port to a compatible submersible pressure gauge or console.
Its flexible, multilayer construction helps you route the hose around your equipment, while the Carbon Black braided finish and nickel-plated fittings provide a practical replacement or upgrade for your existing gauge hose.
Key Features
Flexible braided construction for convenient hose routing.
Carbon Black finish.
Electroless nickel-plated fittings.
Choice of lengths for different equipment configurations.
Suitable for compatible SPGs and consoles.
Technical Specifications
Brand: Miflex
Range: Carbon HD
Hose type: High-pressure gauge hose
First-stage fitting: 7/16″ UNF male
Gauge-end fitting: 7/16″ UNF female
Working pressure: 300 bar
Outside diameter: 7.5mm
Manufacturer’s stated standard: EN250
Colour: Carbon Black
Length: As selected
What’s Included
One Miflex Carbon HD High Pressure Gauge Hose in your selected length.
Manufacturer’s user information and warranty guide.
A pressure gauge, console and gauge swivel pin are not included.
Compatibility & Options
Choose a length that allows suitable routing for your equipment configuration. Check the connections against your regulator and gauge manufacturers’ requirements before ordering.
A compatible swivel pin, also called an airspool, is required to form the internal seal between the hose and a standard SPG or console. This is supplied separately.
Installation should follow the equipment manufacturers’ instructions and be completed by a competent service technician.
Need Some Advice?
Unsure which length or swivel pin your gauge needs? Contact us and the Abyss Scuba School team can help you choose the correct connection for your setup.
